Tridem Axle 40ft Flatbed Trailer (GVW – 52 Tons)

Description

SPECIFICATION:-

UNLADEN WEIGHT OF TRAILER	Approx. 7730 kg.
CHASSIS	500 mm x 125 mm ( 12 mm Top , 10 mm Middle & 20 mm Lower )IS2062 or Equivalent Grade
CHASSIS CROSS	13 – 15 Nos ( 4 mm bending , 10 mm & channel ) IS2062 or Equivalent Grade
FLOOR SUPPORTER	15- 17 Nos ( 125 X 65 Channel & 100 X 50 Channel ) IS2062 or Equivalent Grade
SIDE FRAME	150 X 75 Channel IS2062 or Equivalent Grade
FLOOR	4 mm CHQ sheet IS2062 or Equivalent Grade
KING PIN	2” king pin equivalent to IS : 6763 Part I provided, Make- RSB
LANDING LEG	Two speed landing leg shall be provided at the front end. Make- York / RSB /JAM
SUSPENSION	Heavy Duty Tandem Axle multi Leaf spring suspension & Mono air suspension Make – ( YORK / RSB /JAM ) shall be provided
AXLE	2 Nos. ABS Axle & 1 Nos. Non ABS Axle (1850 Track Length) Make- ( YORK / RSB / JAM ) shall be provided
WHEEL RIM	7.50 x 20 – 12 NOS. MAKE -( TATA /Ashok Leyland ) Shall be provided
TYRE	10.00 x 20 – 12 NOS. Nylon
BRAKES	ABS Kit Make WABCO shall be provided
PAINT	Two Coats of PU high Built Unicoat Paint with colour of customer choice SHALL BE PROVIDED
ELECTRICAL	Parking Lamps, Brake Lamps, and Direction indicator Lamps Fitted in the Trailer MAKE- HELLA & HI-LUX shall be provided
FITMENTS	Fitments such as SUPD, RUPD, Toll Box etc shall be provided
REFLECTORS	Reflecting Tape, Rear Marking Plate, T- Sign MAKE- 3 M shall be provided
WELDING	0.8 mm Mig Wired and 1.2 mm Flux Coated Copper Wires is being used

OPTION AVAILABLE:-

Tyre – Radial

Tridem Axle 40ft Flatbed Trailer (GVW – 52 Tons) | Jain Auto Mart

Need a high-capacity solution for long-haul, heavy-load transport?
Jain Auto Mart proudly introduces the Tridem Axle 40ft Flatbed Trailer (GVW – 52 Tons) — engineered to deliver unmatched strength, load stability, and versatility for logistics companies, construction fleets, and bulk material movers across India.

This trailer is built for:

✅ Long-distance heavy material hauling
✅ Container, construction material & machinery transport
✅ Flatbed versatility for varied cargo types
✅ Load safety and distribution across triple axles

🛠️ Specifications & Highlights:

🚛 40ft platform for diverse cargo handling
⚖️ GVW: 52 Tons – heavy-duty grade
🔩 Tridem Axle for smooth load balancing and road stability
🛡️ Corrosion-resistant frame & reinforced chassis
🧰 Compatible with all standard long-haul trucks

Manufactured with precision and durability, this trailer is ideal for businesses seeking cost-efficient, reliable, and low-maintenance transportation solutions.

Jain Auto Mart – Delivering India’s strongest transport trailers.
